Character:
1.IGBT inverter technology, current controlling model, high quality, steady properties.
2.constant voltage output, high adaptability for electricity network
3.electronic inductor controlling, less splash, deep weld pool and good forming
4.hot start with slow wire feeding, welding with globule wiping off, high hot start success rates.
5.suitable for 0.6mm, 0.8mm thickness welding material
6.small size, light weight, simple operation, multi-process function
7. two display meter for welding current and welding voltage
The efficiency of machine would be above 85%, and machine would be with energy conservation function
Machine function:
1. MIG no gas weld function (tubular wire)
2. ARC weld function (MMA)
3. Lift TIG weld function
Weld current and weld voltage adjustable
wire plate weight: 5kg (can be working with 1kg)
Machine, torch, ground cable.
Model
Power supply: 1-220V+/-15%
No load voltage: 54V
Duty cycle: 60%
Max. working current: 120A
Protection: IP21S
